PRODUCTS: Pneumatic Cylinders |
|
|
STM Series Double Piston Pneumatic Slide Cylinder |
|
|
|
|
|
STM series double piston pneumatic slide cylinder, double force, bore sizes range from 10mm to 32mm. The pneumatic cylinder has high bending resistance and tensional strength performance, well supporting lateral loading performance. Longer slide bearing of the slide cylinder gives much better guiding performance, no need extra lubrication for the double piston pneumatic slide. Two sets of IN/OUT ports are available for more suitable choice, while all sides are designed with suitable mounting holes for the double piston pneumatic slide cylinder. |
|
|
|
|
|
|
|
|
|
|
